“Heavy Duty” HD Series

Felling’s HD Series – X-Force detachable gooseneck trailer line (Heavy Duty) is built with rugged brute strength to tackle the most demanding capacity loads. Load Capacities Ranging from 100,000 lbs. to 120,000 lbs. Distributed in 12’. The HD Series Main Deck is Engineered, Cambered, Fabricated 16” Main Beams and Side Beams, with T-1 Flanges, 10” I-Beam Crossmembers on 24” Centers.
Product Specs
- Capacity: 100,000 lbs. to 120,000 lbs. Distributed in 12’
- GVWR: 118,700 lbs. to 140,000 lbs.
- Deck Height (loaded): 24″ Loaded, 8″ Ground Clearance
Features
- (2) 8” or 10” Lift Cylinders, Depending on Gooseneck Configuration
- Gooseneck: Flip Neck Reinforced, Including Main Frame. (Optional Flip Neck Extension Brackets and Drop-in King Pin – Optional Flip Neck Extension Available up to 168” Swing Clearance)
- Trunnion: Modular Trunnion Approach
- Main Deck: Engineered, Cambered, Fabricated 16” Main Beams and Side Beams, with T-1 Flanges, 10” I-Beam Crossmembers on 24” Centers
- Rear Deck & Trunnion: Stinger Reinforced Trunnion Main Frame (XF-HD-110-3 Single Axle, XF-HD-120-3 Tandem Axle) Plumbing and Brackets
X-Force HD Series Product Sheets
View our trailer model details in the product sheets below. If you’re ready for a quote fill out the request a quote form.
